P5800-D range
|
Rack cabinet 19” and accessories
PASO is one of the few companies in the
business able to boast its own original
integrated design industrialisation and
manufacturing system for a full range of
products, from the most complex and
sophisticated equipment to the simplest
accessories.
The rack containers of the
P5800-D
range have been designed spe-
cifically for housing all PASO electronic equipment and service panels
with provisions for modular fixing in 19’’ racks. All the models of the
range are made of thick reinforced steel sheeting and are available in
black.
A mounting kit consisting of two sides with ventilation slits, an up-
per closing panel and a lower one, four feet, a set of screws for me-
chanical assembly, 4 cables with lugs on the ends for connecting the
equipment to earth and a set of caged nuts for securing the service
equipment. Black front window panels with double locks are available
for opening to the right or to the left (
P5700
range). As an alternati-
ve to the normal rear closing panels secured by screws, black blind
rear doors with locks and ventilation slits are also available (
P5400-D
range).
The racks of the P5800-D range comply with IEC 297-2 and CEI EN
60065 standards. Also, as called for in the general safety regulations
for electrical systems (CEI 64-8, CEI 64-11, CEI 23-48), both the racks
and the various different accessories (doors, closing panels, etc.) are
equipped with the appropriate terminals for connection to earth.
Rack cabinet
from P5808 to P5840-D
Front window panels
from P5712 to P5740
Blind rear doors
from P5416-D to P5440-D
Blind rear panels
P5404-D
P5408-D
P5410-D
