Configuration micro-switches

The main feature of the AX6000 range is the presence of micro-

switches on the rear panel enabling the settings of all the operational

parameters of the equipment to be checked and/or changed. Speci-

fically, it is possible to manage priorities among the various different

audio inputs, to enable a warning signal, to enable VOX (automatic

activation) of the MIC1 input and to programme the zones for calls by

means of a precedence contact and from the telephone/emergency


Connection of stations

With the amplifiers of the AX6000 range, connecting a PMB106-G mi-

crophone station, so as to enable messages to be sent to one or more

receiving zones is simple and quickly done. It is essential to use SFTP

CAT.5E shielded cables (IN UNITS input), and it is possible to connect

up to 16 stations in cascade fashion over a maximum distance of up

to 1 km. If necessary, the bases can be powered by means of their

rear-panel sockets. The output level is adjustable by means of the ap-

propriate front-panel control (MIC/UNITS).


This equipment enables activation/de-activation of BACKGROUND

MUSIC in the chosen zone by means of the switches provided for this

purpose on the front panel. The appropriate LED will light up to confirm

that the music has been activated in the zone in question.

USB/SD card module for the AX6000 range, with remote control

Each amplifier of the AX6000 range has a compartment for housing

an optional module enabling an external device such as an SD/MMC

card or a USB storage unit to be played. The player has a display for

indicating the presence/lack of a SD/MMC/USB medium, the chosen

functions and information about the tracks. A remote control unit is

also provided with the module.

Functional features

• Keys for normal control of how the tracks are played out (PLAY/


• RANDOM function for playing out the tracks at random

• REPEAT function for playing out one or more pieces of choice

• PROGRAM function for playing out a pre-set sequence of pieces

of music

Telephone/Emergency Input

There is a special audio input (TEL/EMERG) on the rear terminal block,

balanced with a transformer and with automatic activation of prece-

dence (VOX). Controls for adjusting the level and the activation th-

reshold are provided on the rear panel. This input can be used for

connecting the appropriate audio output of a telephone switchboard.


USB/SD Card reader

AX6000 range


Mixer amplifiers

120 W, 240 W RMS • 3 output zones
