Accessories
AC50
Pair of side brackets
AC51
Pack of 40 caged nuts (type: M5)
AC52
Pack of 20 screws and 20 washers (type:
M5)
AC54-D
Kit consisting of four wheels, load-bearing
capacity: 65 kg each
AC5801-D
Foundation base for cabinets with cable ou-
tput
P8001-B
Panel with 16 Amp mains switch,
ON/OFF lamp and mains fuse (1 U).
P8002-M
Monitoring panel with 6-position
switch (6 lines), volume control and
loudspeakers (1U ).
P8004
Panel with main 50 Amp circuit-
breaker and ON/OFF lamp. Mo-
nitoring section with 6-position
switches, loudspeaker and volume
control (2 U).
P8003/2-B
Forced ventilation panel complete
with two 230 VAC 50/60 Hz fans
(3 U).
P8008-D
Mains distribution unit with eight
multi-standard sockets.
P8082
Cabled selector switch with 12
switches for activation of the
loudspeaker lines and one main
switch (1 U).
SERVICE PANELS
P8032
Drawer for accessories (3 U).
Perforated panels
equipped with earth terminals.
Blind panels
equipped with earth terminals.
P8035
Top for supporting audio/video
sources and various types of
equipment (adaptable, 2, 3 and 4
U).
P8030
Container for special applications
with mains switch and ON/OFF
lamp.
P5201-D
1 modular unit
P5202-D
2 modular units
P5203-D
3 modular units
P8011-D
1 modular unit
P8012-D
2 modular units
P8013-D
3 modular units
P8014-D
4 modular units
CLOSING PANELS
MODEL
P5808
P5812-D
P5816-D
P5820-D
P5824-D
P5830-D
P5840-D
Modular units
8 U
12 U
16 U
20 U
24 U
30 U
40 U
Techinal specifications
19’’ standard rack consisting of two sides with ventilation slits, an upper closing panel and a lower one, a set of screws for mechanical assembly,
4 cables with lugs on the ends for connecting the equipment to earth and a set of caged nuts for securing the service equipment.
Width
52,5 cm
Depth
45,6 cm
52,5 cm
Height
40,8 cm
58,6 cm
76,4 cm
94,2 cm
112 cm
138,6 cm
183,1 cm
Front door
-
P5712
P5716
P5720
P5724
P5730
P5740
Rear door
-
-
P5416-D
P5420-D
P5424-D
P5430-D
P5440-D
Blind rear panels
P5404-D (4 U), P5408-D (8 U) and P5410-D (10 U)
Colour
Black
Weight
13,35 kg
17,9 kg
21,2 kg
24,8 kg
28,3 kg
33,2 kg
41,6 kg
