AX6000 range
|
Mixer amplifiers
Accessories
AC5660
Brackets for rack-mounting (2 U)
AC50
Lateral supporting brackets for rack-mounting
FUNCTIONAL FEATURES
• 2 balanced/unbalanced mic inputs with phantom power supply
• Microphone input or microphone stations of the
PMB
range
• 2 MIC/PH/LINE inputs with specific selector switch
• 2 auxiliary inputs for sound sources (TAPE/CD)
• Telephone/emergency audio input for priority calls with adjustable
threshold and sensitivity
• Front-panel adjustment of the level of each microphone and
auxiliary input
• Front-panel control of overall volume and of treble and bass tones
• Provisions for inserting a USB/SD CARD module (
AC6000
)
• Constant voltage (50/70/100 V) or 8 Ω impedance loudspeaker
line output.
• 3 output lines for zones
• Balanced line output for connection to other amplifiers
• Output/input for connection to audio processors
• LED-type Vu meter for clear and quick reading of power emitted
• Microswitches for setting operating modes
• Includable/excludable speech filters on all microphone inputs
• Contacts for activating input precedence and override
• “Music On Hold” output with output level control (output of the
selected auxiliary signal)
• Alerting signal (chime) with level control
• Front-panel keys for selecting music listening zones
• Selectable mains power supply - 230/115 VAC or 24 VDC
AX6120
120 W RMS mixer amplifier with 3 output zones
AX6240
240 W RMS mixer amplifier with 3 output zones
This range of built-in amplifiers is characterised by its versatility, user-
friendliness, robustness and reliability, designed for a vast range of
applications in the field of sound-broadcasting for both commercial
and industrial use. The numerous functions offered by the
AX6000
range include three output lines (to zones), CAT5 links to the micro-
phone stations for calling the zones, priority emergency calls to single
zones or groups of zones and provisions for a USB/SD card music
module. The internal CPU is easily able to manage all the many fun-
ctions of the equipment and the micro-switches on the rear panel can
be used to select the required operating model. All the models have
5 inputs with independent front-panel controls and professional XLR
connectors equipped with mechanical locking hold-down devices. The
first two are of the electronically balanced microphone type, with a
phantom power supply (input 1 with automatic VOX activation).
The third can be used either as a microphone input or as an input for
PMB106-G
microphone stations (RJ45 connector) with the possibility
of making calls to zone. The last two can be configured separately, as
microphone inputs (with or without phantom power supplies) or as
line inputs. There are two auxiliary inputs (CD and TAPE) for connec-
ting sources of music, with normalised input levels and a double RCA
socket for using standard stereo cables. There is a special Telephone/
Emergency audio input with automatic activation (VOX) that can be
used for a priority call. If the system requires acoustic correction, it
is possible to connect any equalizer whatsoever or a device for pre-
venting acoustic feedback (Larsen effect) to the PRE OUT and PWR IN
sockets after positioning the control switch provided for this purpose.
The front panel has a compartment for housing an optional
AC6000
module, enabling external devices such as SD/MMC cards and USB
storage units used as sources of music to be played. All the amplifiers
of the range ensure a high degree of reliability thanks to electronic de-
vices protecting them from overload currents and over-temperatures
of the power devices. Each unit also has a cooling fan, with automatic
control of the speed depending on the temperature.
120 W, 240 W RMS • 3 output zones
