MODEL
PA6120
PA6240
Rated power output
120 W
240 W
Constant voltage outputs / Low impedance outputs
100-70-50 V and 8 Ω
Tones control
Bass ± 10 dB (100 Hz) ; Treble ± 10 dB (10 kHz)
Microphone inputs MIC.1 and MIC.2
2 balanced XLR (phantom supply 17,5 V), MIC1 with activation threshold (A.P.T.)
Sensitivity / Impedance
1,2 mV / 1300 Ω
S/N Ratio
> 66 dB
Frequency response
40 ÷ 19.000 Hz
Microphone input MIC.3/UNITS
Balanced XLR (phantom supply 17,5 V) / 1 RJ45 (PMB106-G base station unit)
Sensitivity / Impedance
MIC: 1,2 mV / 1,3 kΩ ; UNITS: 850mV / 800 kΩ
S/N Ratio
MIC: >66 dB ; UNITS: >76 dB
Frequency response
MIC: 30 ÷ 20.000 Hz ; UNITS: 30 ÷ 20.000Hz
Maximum number of microphone station units (PMB106-G)
Up to 16 stations in cascade fashion over a maximum distance of up to 1 km;
if necessary, the bases can be powered by means of their rear-panel sockets
Microphone inputs MIC./LINE 4 and 5
2 balanced XLR with Phantom/Mic/Line selection
Sensitivity / Impedance
MIC: 1,2 mV / 1,3 kΩ ; LINE: 110 mV / 130 kΩ
S/N Ratio
MIC: >66 dB ; LINE: >77 dB
Frequency response
MIC: 30 ÷ 20.000 Hz ; LINE: 30 ÷ 20.000 Hz
Auxiliary inputs
2 RCA (CD + TAPE)
Sensitivity / Impedance
CD: 450 mV / 35 kΩ ; TAPE: 220 mV / 18 kΩ
S/N Ratio
> 80 dB
Frequency response
30 ÷ 20.000 Hz
Telephone / Emergency (TEL / EMERG) audio input
Balanced with terminals (HOT-COM-GND) with activation threshold adjustment
Sensitivity / Impedance
105 mV / 6 kΩ
S/N Ratio
> 74 dB
Frequency response
200 ÷ 20.000 Hz
Line signal outputs
5
LINE OUT
XLR balanced, 1 V / 3,9 kΩ
PRE OUT
RCA, 0,8 V / 3,8 kΩ
TAPE OUT
2 RCA, 0,9 V / 2 kΩ
Music On Hold (MOH) - PRE-AMPLIFIED LINE
terminals (HOT-COM), 2 V / 300 Ω
Music On Hold (MOH) - AMPLIFIED LINE
terminals (GND-MON), 1,9 W / 8 Ω
Mains power supply
230/115 Vac - 50/60 Hz / 24 Vdc
Maximum consumption
280 W (325 VA)
510 W (590 VA)
24 Vdc current consumption (max power / with no signal)
6,8 A / 0,2 A
13,1 A / 0,3 A
19" rack mounting (modular units)
Optional AC50/3 brackets (3U)
Dimensions (W x H x D)
432 x 133 x 360 mm
Weight
14 kg
16,5 kg
External call amplifier
With a single internal amplifier, the compact system functions in the
single-channel mode: a zone call will interrupt the background music
also in those areas not receiving the call. With the PA6000 it is possi-
ble to connect an external dedicated voice amplifier. In this way it will
be possible to receive both announcements and background music in
different zones at the same time.
Music on hold output
The presence of the Music On Hold output (MOH OUTPUT) provides
an interesting function. The signal from the selected sound is always
available, without being subject to any type of precedence. On the ou-
tput terminal block provided for this purpose, there are a balanced line
signal with a transformer (COM-HOT terminals) for connection to other
Calls to zones
The unique feature of this equipment is that the group of zones to
be activated for each available source of calls can be configured: the
PMB106-G microphone stations can be used, directly via the keypad,
to send a call to one or more receiving zones; the announcements
to be made with automatic activation of the MIC.1 input, those to be
made with the emergency input (TEL./EMERG) and those to be made
by closing the precedence contact may affect one or more receiving
zones, depending on the settings made by means of the micro-
switches on the rear panel.
equipment or to a telephone exchange, and a power signal (MON-GND
terminals) for driving directly an 8 Ohm/1 W monitoring loudspeaker.
The output level can be controlled directly from the rear panel.
