DMX8008

|

DMX8008 • Digital matrix mixer 8IN 8OUT

The

DMX8008

is a high performance 8 inputs x 8 outputs digital

matrix mixer.

Specially designed for commercial and professional applicaton such

as Conference rooms, Auditoriums, Sport utility buildings, House

of worship, Pubs and Disco. It includes 8 independently switchable

MIC/LINE inputs with Phantom power supply, 8 Line outputs,

managed by a powerful 48kHz 24 Bit DSP engine, in addition to

high performance 24 Bit AD/DA converters. The DMX8008 supports

a full matrix mixing mode where inputs may be routed/mixed in any

ratio or any output. Each MIC/LINE input channel provides Lo/Hi

pass 1st order filers, 3-band parametric EQ, Noise Gate function and

Gain control. In addition, MIC inputs include a Feedback Eliminator

function, based on a powerful «Pitch Shifting» algorithm, particularly

suitable for voice applications. Automixing function automatically

adjusts input level to make operating easier using either N.O.M.

(Number of Open Mics) attenuation function or Gain Sharing

algorithm.

Ducking Process enforces a «priority order» of open microphones in

order that high-priority inputs atenuate lower-priority inputs. Each

output offers up to 5-band of parametric equalization, crossover

filters, RMS compressor, Peak limiter, Phase and Delay controls; 8

digital IN/OUT ports are provided for general purpose (preset recall,

trigger third parts or device); 8 front knobs provides a quickly way to

control input Gain.

Up to 32 units can be managed by software applications.

functional features

• Excellent audio performance with 24 bit converters coupled

with 48kHz sample rate.

• 8 MIC/LINE inputs, 8 outputs with full matrix mixing, 3-band

parametric equalization and Low/High pass filters per input

channel.

• 5-band parametric equalization per output channel. Each band

can be switched to peaking, Low/High shelving with variable

Q response.

• Crossover filters with slopes from 6dB/Oct. up to 24dB/Oct.

including Butterworth, Bessel, Linkwitz-Riley.

• Gain control, Noise Gate, Feedback eliminator (Mic input only)

per input channel.

• Each output features a precision dynamic range controller

composed of a Peak Limiter and a RMS Compressor with

selectable ratio and variable knee.

• Automixing functions include: configurable N.O.M. attenuation,

Gain sharing algorithm, Priority Ducking.

• Adjustable Delay time up to 380mS per output channel.

• Front panel interactive LCD display for local access and

configuration.

• Front panel 6-led status indicators per IN/OUT channel.

• 8 front knobs available for MIC input Gain control.

• 4 input contacts for additional 4 preset selections with priority

configuration.

• 4 digital output ports for triggering external devices.

• Simultaneous control up to 32 units via PC software - iPad®

• Security lockout.

• TCP/IP, RS 485 and USB connection for remote controls.

DMX8008 Digital matrix mixer 8IN 8OUT

DMP8008 Wall panel for remote control
