Amplified Sinto/USB/SD Card player • 60 W / 120 W / 240 W
PA1000 range
|
CMDS (Compact Music Distribution System)
functional features
• MP3 player module (via USB, SD or MMC card)
• Digital FM tuner
• 3 MIC./LINE inputs with mode selection
• 1 VOX input (INPUT 1)
• 1 auxiliary input for sources of sound (TAPE/CD)
• Front-panel level control for each microphone an auxiliary input
• Front-panel master volume control and treble and bass control
• XLR sockets for connecting dynamic microphones and/or B701-
MG stations
• Constant-voltage (25/70/100 V) or 4Ω impedance loudspeaker
line output terminal block
• Terminal block for activating precedence of microphone inputs
• Output/input for connection to audio processors
• Unbalanced line output for connection to other amplifiers
• LED-type Vu meter for clear and immediate check of output power
• Terminal block for DC power (24 VDC)
• Selectable mains power (230/115 VAC)
• Mountable in standard 19” rack using optional brackets
PA1060
60 W RMS compact system
PA1120
120 W RMS compact system
PA1240
240 W RMS compact system
When it comes to CMDS systems, the
PA1000
range has excellent
functional characteristics and stands out for its exceptionally good pri-
ce/performance ratio. A multi-function module with a digital FM tuner,
an MP3 player for a USB/SD-MMC card, an amplifier-mixer and the
wide range of possible configurations make each of these units a ver-
satile sound-broadcasting system able to cover the needs of any small
or medium-sized installation. The XLR sockets on the rear panel can
be configured separately as microphone inputs (with or without phan-
tom power supplies) or as line inputs: the mode is selected by means
of the specific three-position switches.
Each of these inputs has its own level control for metering the ampli-
tude of the various different signals suitably. Furthermore, the INPUT1
microphone input has an automatic precedence function (VOX): when
the microphone connected to this input is used to speak, all the music
and microphone inputs will automatically be muted. For connection to
external music sources there is an auxiliary input with a double RCA
socket for using standard stereo cables. It is possible to connect all
dynamic microphones and
B701-MG
microphone bases to PA1000
compact systems. A precedence terminal block on the rear panel ena-
bles signals fro, the MP3 player, from the tuner and from the auxiliary
input to be muted.
If, due to a particularly difficult environment, the system requires acou-
stic correction, it is possible to connect any equalizer whatsoever or
a device for preventing acoustic feedback (Larsen effect) to the PRE
OUT and PWR IN sockets. All the models ensure a high degree of re-
liability thanks to electronic devices protecting them from overload
currents and over-temperatures of the power devices. Each unit also
has a cooling fan, with automatic control of the speed depending on
the temperature.
Accessories
AC5660
19" rack mounting brackets (2U)
