Ceiling mounting
|
CSPOT range • “SPOT LIGHT” ceiling-mounting
C470 range
CSPOT
ceiling-mounting units are designed specifically to meet the
aesthetic requirements of modern interior design.
The small size and the shape of the structure of this speaker unit
meet the need to camouflage the presence of the loudspeaker among
the decorative and/or functional elements of the ceiling, e.g. flush-
mounted lighting fixtures. The structure is made of painted metal, ma-
king it a tough product with fine construction details.
The loudspeaker features an excellent performance in spite of the
fact that it is smaller than the usual units for ceiling mounting. In-
stallation in false ceilings is simple and rapidly accomplished thanks
to the spring-type hooks. The built-in transformer enables connection
to constant-voltage lines with adjustable power. The models of the
CSPOT range are available in several different colours.
CSPOT/6-TS
6 W, silver, Ø 105 mm
CSPOT/6-T
6 W, white Ø 105 mm
The speaker units of the
C470
range for installation in false ceilings
are white, with an ABS housing and metal protecting grille. The sim-
ple and discreet design and good reproduction of both speech and
music enable it to fit perfectly into any architectural environment The
simple spring-type fixing system makes installation quick. The built-in
transformer enables it to be connected to constant-voltage lines with
variable power.
The speaker units of the C470 range are characterised by their com-
pact size and their sealed structure. They are recommended for parti-
cularly damp places. They have an ABS rear part, a sealed cable gland
and a connecting cable made up of several leads.
C470/6-TW
6 W, ABS, IP55, Ø 140 mm
CSPOT/6-TN
6 W, black, Ø 105 mm
MODEL
CSPOT/6-T
CSPOT/6-TN
CSPOT/6-TS
C470/6-TW
Rated power
6 W
Adjustable power
6 / 4 / 2 W
6 / 3 W
Characteristics
Metal structure
ABS housing, metal front grille
Loudspeakers
1 broadband
Sound pressure SPL (Pnom/1m)
95 dB
98 dB
Efficiency (1W/1m)
86 dB
91 dB
Frequency response
100 ÷ 20.000 Hz
150 ÷ 18.000 Hz
Dispersion angle @2kHz
130°
160°
Protection degree
-
IP 55
Mounting hole
Ø 85
Ø 125 mm
Colour
White
Black
Silver
White
Dimensions (W x H x D)
Ø 105 x 85mm
Ø 140 x 130 mm
Weight
0,5 Kg
0,9 kg
