77 / 98
77
C51-HF range
C59 range • Pendant speakers
The spherical speaker units of the
C59
range, characterised by an
excellent frequency response and ease of use, are suitable for use
also in environments that are particularly difficult from the acoustic
and plant engineering points of view. They are designed for suspended
installation, meeting the requirements of quality sound broadcasting
even in large rooms with high ceilings.
These elegant and discreet units feature a white ABS structure and
are equipped with constant-voltage line transformers with adjustable
power plus devices for securing to the ceiling and a 4 m cable.
C59-T
15 W ABS spherical speaker
The
C51/20-HF
is a high-quality and high-power two-way speaker
unit for ceiling mounting. It has a white ABS structure with a rear cap
and a quick-fitting securing system with hooks. It has all the features
required for use in fixed installation and provides high intelligibility of
speech and powerful and natural reproduction of music.
C51/20-HF
20 W, ABS, Ø 203 mm
MODEL
C59-T
C51/20-HF
Rated power
15 W
20 W
Adjustable power
15 / 7,5 / 3,75 W
20 /10 / 5 / 2,5 W
Characteristics
ABS housing
ABS housing
Loudspeakers
1 broadband
1 two-cone broadband
Sound pressure SPL (Pnom/1m)
100 dB
101 dB
Efficiency (1W/1m)
90 dB
88
±
³ dB
Frequency resp onse
70 ÷ 20.000 Hz
100 ÷ 20.000 Hz
Dispersion angle @2kHz
80°
180°
Protection degree
IP 44
IP 44
Hooks / Mounting hole
Device for securing to the ceiling and a 4 m cable
Ø 170 mm
Colour
White
Dimensions (W x H x D)
Ø 202 x 176 mm
Ø 203 x 145 mm
Weight
1,8 Kg
1,8 kg
