AC901
C44 range
Flush-mounting speakers
|
Rectangular two-way speaker units for flush-mounting on walls or in
false ceilings. Their performance is excellent for reproducing music
and speech. They are ideal in refined environments such as wellbeing
centres, hotels and conference halls. They are white and made of
ABS with a metal front grille. Each speaker unit has a transformer for
connection to constant-voltage lines. They are equipped with special
hooks for enabling direct installation in false ceilings. For easy flush-
mounting in a wall, (optional)
AC941
boxes should be used.
C41/10-HF
10 W, two-way, flush-mounting (wall/false ceiling)
Accessories
AC941
Wall-mounting box (210 x 155 x 70 mm)
C44/12-EN
12 W, EN 54-24 certified
MODEL
C44/6-TB
C44/20-TB
C44/12-EN
C41/10-HF
Rated power
6 W
20 W
12 W
10 W
Adjustable power
6 / 3 / 1,5 W
20 / 10 / 5 / 2,5 W
12 / 6 / 3 W
-
Characteristics
UL94-V0 ABS body, metal front grille
ABS body, metal front grille
Loudspeakers
1 broadband
1 two-cone broadband
1 broadband
1 Wf + 1 Tw
Sound pressure SPL (Pnom/1m)
97 dB
103 dB
99 dB
98 dB
Efficiency (1W/1m)
90 dB
90 dB
89 dB
88 dB
Frequency response
150 - 13.000 Hz
100 ÷ 15.000 Hz
150 ÷ 15.000 Hz
120 ÷ 20.000 Hz
Dispersion angle @2kHz
120°
120°
170°
Mounting
AC901 optional box for flush-mounting
Flush-mounting wall/ceiling box
False ceiling (hole: 118 x 193 mm)
AC941 box for flush-mounting
Colour
White
Dimensions (W x H x D)
165 x 280 x 70 mm
165 x 280 x 90 mm
148 x 222 x 68 mm
Weight
0,83 kg
1,38 kg
2 kg
1,3 kg
Accessories
AC901
Wall-mounting box (162 x 276 x 78 mm)
The ideal application for speaker units of the
C44
range is in hospitals, ho-
tels, offices, schools, shops or anywhere where flush-mounting and a discreet
and elegant appearance are required. Each unit is made of self-extinguishing
plastic material UL94-VO with a metal front grille. Two models are available,
with an output power of 6 and 20 W with a line transformer respectively. The
(optional)
AC91
box for flush-mounting makes wall-mounting easy and quick.
C44/6-TB
6 W flush-mounting
C44/20-TB
20 W flush-mounting
C41 range
Models
C44/12-EN
were designed
specifically for use in emergency and
evacuation systems (VES). Each unit
has a ceramic terminal block and a
thermal fuse. They are certified for
compliance with
EN 54-24:2008
.
The metal box for flush-mounting
makes this operation easy and quick,
with spring-mounted hooks (included
in the supply).
EN54
16
EN54
24
EN54
16
EN54
24
