57 / 98
57
C94/15-T
C94/15-TN
C94/30-T
C94/60-T
C94/30-T
30 W, two-way, bass-reflex, white
C94/30-TN
30 W, two-way, bass-reflex, black
C94/60-T
60 W, two-way, bass-reflex, white
C94/15-T
15 W, two-way, bass-reflex, white
C94/15-TN
15 W, two-way, bass-reflex, black
C94/30-TN
Wall-mounting speakers
|
C94
sound speakers have been created and designed in Italy. Their
exclusive and elegant design allows the loudspeakers to be used for
any installations and environment, keeping the same high quality
sound throughout. The C94 range, made of ABS with a front metal
grille, utilizes a compact two-way system guaranteeing high perfor-
mances, wide dynamics, high fidelity sound reproduction and high
voice intelligibility. C94 speakers are equipped with an exclusive ful-
ly adjustable support bracket for easy installation, to cut costs and
save installation time. The bracket may be attached to the wall prior
to installing the loudspeaker and is provided with a safety cable. Con-
nection to the loudspeakers is via plug in “Euroblock” connector and
adjustment of loudspeaker output is made via screwdriver adjustable
switch.
MODEL
C94/15-T
C94/15-TN
C94/30-T
C94/30-TN
C94/60-T
Rated power
15 W (30 W / 8 Ω)
30 W (60 W / 8 Ω)
60 W
Adjustable power
15 / 7,5 / 4 / 2 W
30 / 20 / 15 / 10 W
60 / 45 / 30 / 15 W
Impedance
8 Ω
Characteristics
ABS body, metal front grille
Loudspeakers
1Wf + 1Tw (bass-reflex)
Sound pressure SPL (Pnom/1m)
100 dB
106 dB
111 dB
Efficiency (1W/1m)
85 dB
87,5 dB
90 dB
Frequency response
100 ÷ 15.000 Hz
85 ÷ 15.000 Hz
70 ÷ 20.000 Hz
Dispersion angle @2kHz
120°
100°
90°
Mounting
Wall mounting bracket (supplied)
Colour
White (RAL 9016)
Black
White (RAL 9016)
Black
White (RAL 9016)
Dimensions (W x H x D)
143 x 204 x 162 mm
168 x 240 x 180 mm
218 x 312 x 219 mm
Weight
1,5 kg
2,3 kg
4,5 kg
C94 range
168 (218 for C94/60-T only)
180 (219 for C94/60-T only)
143
162
204
240 (312 for C94/60-T only)
