C86/20-TW
20 W, aluminium vandal-proof housing, IP65
C86/20-EN
20 W, EN54-24 certified
The vandal-proof sound projectors of the
C86
range feature a grey
aluminium housing and a yellow-galvanised front grille, tropicalised
and stove-enamelled. Thanks to the particularly tough and sealed de-
sign, class of protection IP65, this range is especially suitable for use
in particularly difficult environmental conditions.
They have wide-band loudspeakers featuring a high level of acoustic
efficiency for excellent reproduction of both voice and music. Each unit
is supplied with a swivelling fixing bracket that slides along the hou-
sing and a transformer for 100/70/50 V constant-voltage lines with an
output power adjustable to 20-10-5 W.
(cert. No.
0068-CPR-039/2016
).
MODEL
C86/20-TW
C86/20-EN
C86/20-2TW
C86/20-2EN
Rated power
20 W
20 W (10+10 W)
Adjustable power
20 / 10 / 5 W
Characteristics
Aluminium housing and a stainless steel front grille
Loudspeakers
1 broadband
2 broadband
Sound pressure SPL (Pnom/1m)
105 dB
100 dB
Efficiency (1W/1m)
92 dB
87 dB
Frequency response
150 ÷ 15.000 Hz
Dispersion angle @2kHz
100°
2 x 110°
2 x 140°
Protection degree
IP 65
Mounting
Swivelling bracket
and connecting cable
Swivelling bracket and flame-proof
connecting cable
Fixed bracket
and connecting cable
Fixed bracket and flame-proof connec-
ting cable
Colour
Light grey body, black front grille
Dimensions (W x H x D)
180 x 145 x 178 mm
Weight
2,4 kg
2,85 kg
2,90 kg
Sound projectors
|
Aluminium
C86/20-2TW
Bi-directional 10+10 W, vandal-proof housing, IP65
C86/20-2EN
Bi-directional 10+10 W, EN54-24 certified
C86 range • Vandal-proof housing
The models with the suffix
-EN
were designed specifically for use in
emergency and evacuation systems (VES). Each unit has its own ther-
mal fuse that excludes the loudspeaker in the event of overheating plus
a flame-proof connecting cable (80 cm in length); they are certified for
compliance with
EN 54-24:2008
(cert. No.
0068-CPR-033/2013
and
0068-CPR-039/2016
). The
C86/20-2TW
and
C86/20-2EN
two-directional sound projectors are particularly suitable for installa-
tion in transit areas or corridors.
EN54
16
EN54
24
EN54
16
EN54
24
EN54
16
EN54
24
EN54
16
EN54
24
