P8083 range
|
Music sources
P8083-R • Digital USB/SD Card player/recorder
Module available on request
A single container that can be mounted in a standard 19” rack and
is one modular unit high, comprises a CD-MP3/USB/SD Card player
and an FM/AM stereo tuner. Volume control and independent audio
outputs on a double RCA socket for both sources of sound. There is an
additional combined audio output from which it is possible to pick up
both signals of the modules with priority of the CD player over the tu-
ner. The CD player module has a back-lit display, a shockproof system,
Other models created by combining various different modules of the
P8083 range are available on request. They all feature a standard con-
tainer suitable for mounting in a standard 19” rack and of the height of
one modular unit. Double RCA sockets are provided for connecting the
line outputs on the rear panels, using standard stereo cables.
Power supply requirements: 230/115 VAC - 50/60 Hz / 24 VDC.
Size (LxHxD): 482 x 44 x 285 mm
The
P8083-R
is a digital recorder and player for audio files in MP3
format on external storage devices such as SD cards or USBs (playing
of MP3/WMA audio files and recording in MP3 format). Front-panel
master volume control. Rear-panel line input and output on a double
RCA socket. Management of external storage devices from 128 MB
to 16 GB (SD Card/USB). Possibility of selecting the recording quality
(128 Kbps or 192 Kbps). Recordable audio tracks up to a maximum
of 99. It is possible to programme customised sequences for playing
P8083-2T
Two FM/AM stereo tuners.
P8083-T
FM/AM stereo
tuner. Master
volume control,
backlit display,
automatic and
manual tuning, pre-selection of up to 20 stations (10 FM and 10 AM
stations) and SLEEP function. FM and AM aerial included in the supply.
P8083-P
CDM-P3/USB/
SDCARD play-
er with PITCH
speed control.
Master volume
control and control of speed at which the audio tracks are played out
(PITCH). Backlit display, shock-absorbing system and normal, repeat,
random or programmed play functions. Remote control included in
the supply.
P8083-ALL
CDM-P3/USB/
SD CARD play-
er and FM/AM
tuner. Master
volume con-
trol. Backlit display. CD player with shock-absorbing system. normal,
repeat, random or programmed play functions. Tuner with automatic
scanning and pre-selection of up to 20 stations (10 FM and 10 AM
stations). Remote control and aerials included in the supply.
P8083-2ALL
Model with two CD-MP3/USB/SD CARD player module and FM/AM
stereo tuner module.
and normal, repeat, random or programmed play functions. The CD
player is supplied with a remote control enabling full remote manage-
ment. Stereo FM/AM tuner module with backlit display, automatic and/
or manual tuning, pre-selection of up to 20 stations (10 FM plus 10
AM), and SLEEP function. FM and AM aerial included.
Power supply requirements: 230/115 VAC - 50/60 Hz / 24 VDC.
Size (LxHxD): 482 x 44 x 285 mm
out the music and to select and repeat a single section of a piece of
music. Files can be deleted and it is possible to copy data from a USB
to an SD card or vice versa. Large backlit display for showing the va-
rious different functions. A remote control enabling full remote mana-
gement is supplied with the equipment. The P8083-R has provisions
for mounting in a standard 19” rack and has the height of a single unit.
Power supply requirements: 230/115 VAC - 50/60 Hz / 24 VDC.
Size (LxHxD): 482 x 44 x 285 mm
P8083 • CD-MP3/USB/SD Card player and FM/AM stereo tuner
