Accessories
AC50/3
Brackets for rack-mounting (3 HE)
The
PA6240
and
PA6120
compact systems combine in a single
container a multi-function sound source (CD-MP3 player, USB, SD/
MMC card and AM/FM tuner) and an amplifier-mixer, 120 W and 240
W RMS respectively, with six output zones and separate volume con-
trol. They have an internal CPU able to manage easily the many fun-
ctions of the equipment. Specific micro-switches on the rear enable
the desired operating mode to be selected.
Designed starting out from the amplifier-mixers of the AX6000 range,
all PA6000 models have five inputs with independent front-panel con-
trols and with professional XLR connectors with mechanical holding
devices. The first two are of the electronically balanced microphone
type, with a phantom power supply (input 1 with automatic VOX acti-
vation). The third can be used either as a microphone input or as an
input for PMB106-G microphone stations (RJ45 connector) with the
possibility of making zone calls. The last two can be configured sepa-
rately, as microphone inputs (with or without phantom power supplies)
or as line inputs.
There are two auxiliary inputs (CD and TAPE) for connecting to external
sources of music, with normalised input levels and a double RXA so-
cket for using standard stereo cables.
There is a special Telephone/Emergency audio input with automatic
activation (VOX) that can be used for a priority call. If the system requi-
res acoustic correction, it is possible to connect any equalizer whatso-
ever or a device for protection against acoustic feedback (Larsen ef-
fect) to the PRE OUT and PWR IN sockets after positioning the control
switch provided for this purpose. All the models of the range ensure a
high degree of reliability thanks to electronic devices protecting them
from overload currents and over-temperatures of the power devices.
Each unit also has a cooling fan, with automatic control of the speed
depending on the temperature.
functional features
• 2 balanced/unbalanced microphone inputs with phantom power
supplies
• Microphone input or microphone bases of the PMB range
• 2 MIC/PH/LINE inputs with associated selector switch
• 2 auxiliary inputs for sound sources (TAPE/CD)
• Telephone/emergency audio input for priority calls with adjustable
threshold and sensitivity
• Front-panel level controls for each microphone and auxiliary input
• Front panel overall volume control and treble and bass controls
• Multi-purpose sound source module with CD-MP3/ USB/SD CARD
player and AM/FM tuner
• Constant voltage (50/70/100 V) or 8Ω impedance loudspeaker
output lines
• 6 output lines (zones) with front-panel level control for the music
signal for each single zone
• Balanced line output for connection to other amplifiers
• Output/input for connection to audio processors
• Connection to an external amplifier for simultaneous music and
speech in different zones
• LED-type Vu meter for clear and immediate monitoring of output
power
• Microswitches for setting the operating modes
• Inclusion/exclusion of speech filter on all microphone inputs
• Contacts for activating input precedence and override
• “Music On Hold” output with output level control (output of
selected auxiliary signal)
• Alerting signal (chime) with level control
• Selectable 230/115 Vac and 24 Vdc mains power supply
PA6120
120 W RMS compact system with 6 output zones
PA6240
240 W RMS compact system with 6 output zones
PA6000 range
|
CMDS (Compact Music Distribution System)
Amplified Sinto-CD/mp3 and USB/SD Card player • 6 output zones
