Only open conference units
B2080-DG
Delegate unit for open conference
Each
B2080-DG
station enables the delegate to take an active part
in the discussion and to listen clearly to the contributions of the other
speakers via the built-in loudspeaker or via an external headpho-
ne. Each unit is supplied with its own cardioid electret microphone
mounted on a 43-cm long flexible stem and a ring that lights up to
indicate that it has been activated. Each station also has a push-button
for requesting to speak, a built-in loudspeaker that is automatically
excluded when the station is
active and a volume control.
Delegates can also listen to the
discussion via headphones or
earpieces to be connected to
the sockets provided for this
purpose (3.5 mm jack). As
soon as a jack is connected,
the built-in loudspeaker is mu-
ted. A double RJ45 socket (IN/
OUT) on the rear panel enables
cascade connection to the
other stations or to the con-
trol unit, using CAT5e SF/UTP
shielded cable.
NB.
: a B2080-DG micropho-
ne station can be used with
the CS2100 system to act as
“non-voting” delegate or, if sui-
tably configured, as a Secreta-
ry, with the possibility of step-
ping in directly without having
to queue to speak.
B2080-PG
Chairman unit for open conference
Each
B2080-PG
unit has the same features described above for
B2080-DG delegate stations, plus the possibility, using the double key,
to join in a conversation or to activate the Priority function. The Priority
control excludes off all the other microphones.
Each unit is supplied with its own cardioid electret microphone
mounted on a 43-cm long flexible stem and a ring that lights up to
indicate that it has been activated. Each unit also has a push-button
for requesting to speak, a
built-in loudspeaker that
is automatically excluded
when the station is active
and a volume control. The
chairperson can also listen
to the discussion via a he-
adphone or an earpiece to
be connected to the socket
provided for this purpose
(3.5 mm jack). As soon as
the jack is connected, the
built-in loudspeaker is mu-
ted. A double RJ45 socket
(IN/OUT) on the rear panel
enables cascade connec-
tion to the other stations or
to the control unit, using CA-
T5e SF/UTP shielded cable.
1. Input/output connectors
2. Socket for headset
B2080 - B2100
MODEL
CL2100-G
B2100-DG
B2100-PG
B2080-DG
B2080-PG
Conference mode
Conference and voting
Only open conference
Unit type
Control console unit
Delegate unit
Chairman unit
Delegate unit
Chairman unit
Suitable central control unit
CS2100
CS2100, CS2080
CS2080
Microphone
-
43-cm long stem flexible at the base, electret microphone
Digital display
16 digits x 2 lines
-
Headset output
-
Stereo jack type outlet (3.5 mm)
Connecting plugs
2 x RJ45
System connecting cables
CV20xx cables with RJ45 connectors (not included) or 31/142-100 (CAT5e SF/UTP shielded cable, 100 m roll)
Mounting
Desktop (AC700 fixing mounting optional kit)
Dimensions (W x H x D)
116 x 32 ÷ 60 x 200 mm
116 x 32 ÷ 60 (490 with microphone) x 200 mm
Colour
Light grey
Weight
0,5 kg
0,6 kg
Accessories
AC700
Fixing mounting kit for B2080, B2100 and CL2100-G units
