PAW4500-VES range


Voice Evacuation System

PAW4500-VES range • 500W Voice Evacuation System for wall mounting

The new


compact systems - equipped with a


16 certified control unit

- have been designed for ease of installa-

tion and for operating in a vast range of applications.

These systems are able to manage, depending on the model, up to

6 alarm zones via local controls,

remote microphone station and controlled inputs.

Three available models:

• PAW4502-V 2 zones - double line

• PAW4504-V 4 zones - double line

• PAW4506-V 6 zones - double line

(cert. No.



functional features

• Audio rated power: 500 W freely distributed between the zones up

to a maximum of 250W within a single zone.

• 4.3” touch screen back-lighted display for alert & evacuation zone

selection, levels adjustment, settings and failure visualization.

• Fireman’s monitored microphone on the front panel.

• Sending of EVACUATION and ALERT pre-recorded messages.

• 7 monitored inputs, each of which is conf gurable for the playback

or either evacuation or alert messages, programmable for each

zone, or for the reset of the messages.

• 1 auxiliary input for external sound sources.

• 1 VOX input.

• 3 configurable relay outputs.

• Double output A+B per zone.

• Secure front-panel button for operating the emergency system

complete with LED indicator.

• Front-panel reset button.

• Possibility to source either BGM or paging announcements from

an auxiliary input or microphone.

• Possibility to connect up to 16 paging units PMB106-G,


• Possibility to connect up to 4 remote emergency microphone units

PMB132/12-V, PMB132-V or, as an alternative, up to 2 touch

screen remote emergency microphone units TSB8500-V.

• Possibility to connect further PAW4500-VES (up to 6 units).

• Industry-standard 19” rack-mounting format (optional).

PAW4502-V 500W 2-zone wall VES system

PAW4504-V 500W 4-zone wall VES system

PAW4506-V 500W 6-zone wall VES system
