55 / 98
55
B20-N
B13-N
Accessories for microphone bases
|
F11-C
Flexible support, with microphone XLR socket,
balanced shielded cable (1.1 m) with XLR plug.
L.: 40 cm. Dia.: 14 mm.
B13-N
Floor stand, complete with telescopic
rod and folding tripod. With adjustable
height and microphone boom.
Height: 92÷152 cm
Base spread: 70 cm
Weight: 2.5 kg
B116-B
Table-top base in black cast-iron, with chro-
miumplated telescopic rod, adjustable from 37
to 60 cm. For microphone supports S1, S8 and
S10.
B20-N
Floor stand with circular cast metal supporting
structure. Telescopic rod with adjustable
height and painted black tubular metal.
Height: 95÷175 cm
Base width: 30 cm
Weight: 4 kg
F5- N
Flexible support with threaded (16x1) male
and female ends. To be used between the
B12, B60-N and B70 and the S1, S8 and S10
supports. Length 40 cm. Dia 14 mm. Black,
without cable.
MC30-GN
Electret microphone with a cardioid polar re-
sponse and flexible support. It’s equipped with
a 5-poles DIN male connector. It is possible to
use with AC14-B preamplifier card.
Length: 44 cm
Frequency response: 100÷20000 Hz
Sensitivity: -67 dBV/μbar. Impedance: 680 Ω
CV2002
CAT5e SF/UTP shielded cable, length 2 m, with RJ45 connectors
CV2005
CAT5e SF/UTP shielded cable, length 5 m, with RJ45 connectors
CV2010
CAT5e SF/UTP shielded cable, length 10 m, with RJ45 connectors
31/142-100
CAT5e SF/UTP shielded cable, 100 m roll
31/2 -100
Shielded microphone cable (2 wires + shield), 100 m roll
31/84-100
Shielded cable (2 wires and 2 wires + shield), 100 m roll
31/65-250
CEI 20-22 II cable, (3 wires + 1 shielded wire), 250 m roll
CV15
5 m microphone extension cable, complete with male and female XLR connectors
CV24
10 m microphone extension cable, complete with male and female XLR connectors
CV27
1 m shielded cable, complete with 5-pole DIN connectors
CV28
1 m shielded cable, complete with 5-pole DIN and phono RCA connectors
CV33
1,5 m shielded cable, complete with phono RCA connectors
CV37
1,5 m cable DB9/CAT5 adaptor (PMB106-G and PMB112-G microphone station units)
AC14-B
Pre-amplifier module for dynamic and electret
microphones. Screw connectors. Suitable to
install into standard electric box (e.g. 27/901).
Balanced audio output. Sensitivity and output
signal level can be adjusted. It has provisions
for connection to a LED and a push-button ac-
tivation.
Power supply: 12/24 Vdc
Dimensions: 74 x 50 x 10 mm
