MA855/R850A
Hand-held wireless microphone unit
Wireless microphones and accessories
|
Wireless microphones UHF multi-channel
Accessories for microphones and microphone bases
The
MA855/R850A
and
MA853/R850A
kits are wireless micro-
phone systems of the Diversity UHF type featuring high performance
levels and PLL technology. They enable selection of 120 channels for
maximum flexibility. The “Diversity” technology of the receiver and the
microphone antenna ensure an exceptionally broad range for maxi-
mum reliability of the signal and freedom of movement.
Both transmitters (MA855A with a handgrip and MA853A pocket mo-
del) have a handy mute function, an LCD display, a keypad lock and a
battery-status indicator.
The R850A receiver, which has its own power supply, is equipped with
an automatic scanning system for identifying the frequency of the mi-
crophone, a large LCD display, an RF/AF level measuring device and a
squelch circuit that enables any interferences present in the surroun-
ding environment to be eliminated.
Accessories
AC850
Support for rack mounting of one R850A receiver (1 U)
AC852
Support for rack mounting of two R850A receivers (1 U)
AC855
Battery charger for MA855A and MA853A transmitters
MA853/R850A
Lavalier wireless microphone kit
MODEL
MA855/R850A
MA853/R850A
Characteristics
- Hand-held wireless microphone with dynamic capsule
- 120 channels
- Pocket wireless microphone with electret capsule
- 120 channels
Carrier frequency
638 ÷ 662 MHz (UHF)
RF sensitivity
-100 dBm/30dB
Frequency response
50 ÷ 15.000 Hz
Receiver output level
Balanced XLR, 25 mV
Unbalanced Jack 6,3 mm, 750 mV
Operating range (line of sight)
100 m
100 m
Mains power supply
- R850A receiver: 12 Vdc/ 500 mA
- MA855A or MA853A transmitter: AA (2 off) or rechargeable NiMH batteries
Supplied accessories
AC/DC power supply unit, audio LF cable, 2 antennas, color ID caps
AC/DC power supply unit, audio LF cable, 2 antennas, windscreen
19" rack mounting (modular units)
AC850 optional support for one R850A receiver (1 U)
AC852 optional support for two R850A receiver (1 U)
Dimensions (W x H x D)
MA855A transmitter: 51 x 278 mm
R850A receiver: 210 x 46 x 159 mm
MA853A transmitter: 70 x 98 x 23 mm
R850A receiver: 210 x 46 x 159 mm
Weight
MA855A transmitter: 240 g
R850A receiver: 0,95 kg
MA853A transmitter: 90 g
R850A receiver: 0,95 kg
S1
Jointed microphone support, can
be screwed onto telescopic
table-top or floor bases.
B60-N
Chromium-plated ring-nut for
table-top mounting, black.
Provisions for using F5-N or
F11-C flexible stems.
Dimensions: Ø 4.5 cm.
B160
Table-top base for
MC30-GN micro-
phones, complete
with shielded cable
(L) 100 cm. Size: Ø 4.5 cm;
(H) 4.2 cm.
B70-N
Chromium-plated ring-nut
for table-top mounting,
black. Provisions for using
F5-N or F11-C flexible
stems.
Dimensions: Ø 6.5 cm.
B12
Cast-iron table-top base,
black, for F5-N and F11-C fle-
xible stems.
27/59
Adaptor for screwing supports
S1 and S10 onto the pins of
telescopic bases with M12 x 1
or 3/8” threads.
S8
Jointed support for micropho-
nes and wireless microphones
with spring-type seal.
S10
Same features as the S1, with
vibrationdamping elastic body.
