51 / 98
51
Dynamic microphones
Microphones
|
MC102 • MC102-N
Ultra-flat surface microphones with a
hemi-cardioid polar pattern. They are
used on flat horizontal surfaces (ta-
bles, floors). Their peculiar directivity
characteristics (60° from the front in
respect of the surface on which they
rest) makes them particularly suitable
for conferences, religious ceremonies
and/or theatrical events.
Phantom power supply and 5-metre
long cable with carrier case.
MC250
Pen microphone with a hyper-cardioid polar pattern. It ensures high
levels of useful signal with a limited receiving angle, thus keeping the
impact of surrounding noises to a minimum. It has a very extensive
frequency response. It is suitable also for critical receiving situations at
some distance from the source with minimum sensitivity to the Larsen
effect. Phantom power supply. It has a voice-filter switch, a 4.5-metre
long cable, a coupling for mounting on a stem, a wind screen and a
carrier case.
Electret microphones
M1-NC
Unidirectional dynamic microphone with PTT push button,
1.5 m spiralled cable and XLR plug.
M976
Very sensitive one-directional dynamic microphone with
a hyper-cardioid pattern, suitable for use for both speech
and music. Its special elastic suspension and its high de-
gree of directivity make it advisable also in difficult situations
with acoustic feedback problems (Larsen effect). It has an
ON/OFF switch and a 5-metre long XLR/XLR cable, a coupling
for mounting on a stand and a handy carrier case are included
in the supply.
M936
Unidirectional dynamic microphone with a cardioid pattern
for general use. It features high sensitivity, particularly good
intelligibility of speech and good reproduction of music. The
supply includes an ON/OFF switch, a 5-metre XLR/XLR
cable, a coupling for mounting on a stand and a carrier
case.
MC260 • MC265
Family of electret microphones featuring an elegant appearance and
able to meet the increasingly demanding specifications of architec-
tural design and interior decoration of halls, conference rooms and
places of worship. The cardioid type response of the microphone hou-
sing and the very sensitive electret capsule make these microphones
perfect for enhancing the user’s oratory qualities.
B260
Table-top base for MC260 and MC265 mi-
crophones. ON/OFF switch, XLR/F connector
with mechanical locking device for fitting
a microphone and rear XLR/M output con-
nector. Black die-cast zinc structure. Size
(LxHxD): 120 x 40 x 125 mm. Weight: 1.2 kg.
MC265
Electret microphone stem flexible at the base, 42 cm long
MC260
Electret microphone with a double-jointed stem 55 cm long
MODEL
M1-NC
M936
M976
MC102
MC250
MC265
MC260
MC102-N
Characteristics
Dinamic unidirectional,
cardioid
Dinamic unidirectional,
hypercardioid
Electret unidirectional,
hemicardioid
Electret, hypercardioid
Electret, cardioid
Power supply
-
Phantom 11 ÷ 52 Vdc
Phantom 9 ÷ 52 Vdc
Impedance
600 Ω
600 Ω
600 Ω
100 Ω
150 Ω
200 Ω
Sensitivity
–78 dB/ µbar
–72 dB/µbar
–71 dB/µbar
–65 dB/µbar
–54 dB/µbar
–58 dB/µbar
Frequency responce
100 ÷ 10.000 Hz
50 ÷ 15.000 Hz
50 ÷ 16.000 Hz
50 ÷ 16.000 Hz
20 ÷ 20.000 Hz
50 ÷ 18.000 Hz
Body
ABS
Die-cast Zn-Al
Die-cast Al
Brass
Brass
Finish
Black
Anthracite grey mat
White (MC102)
Black mat
Black
Black (MC102-N)
Supplied accessories
1,5 m spiralled cable (XLR)
5 m detachable cable (XLR),
jointed microphone support
and shock-proof carrying case
5 m detachable cable
(Micro-XLR/ XLR) and
shock-proof carrying case
4,5 m detachable cable
(XLR) jointed microphone support
and shock-proof carrying case
-
Dimensions (W x H x D)
100 x 60 x 50 mm Ø 53 x 170 mm Ø 53 x 170 mm
90 x 17 x 115 mm
Ø 23 x 163 mm
Ø 19 x 424 mm Ø 19 x 550 mm
(Ø 7 stem)
(Ø 7 stem)
Weight
165 g
236 g
290 g
264 g
148 g
124 g
140 g
