MODEL
AX3506
AX3512
Rated power output
60 W
120 W
Constant voltage outputs / Low impedance outputs
100-70-50 V and 8 Ω
Tones control
Bass ± 10 dB (100 Hz) ; Treble ± 10 dB (10 kHz)
Microphone inputs MIC.1 and MIC.2
2 balanced XLR (phantom supply 17,5 V), MIC1 with activation threshold (A.P.T.)
Sensitivity / Impedance
0,9 mV / 900 Ω
S/N Ratio
>62 dB
Frequency response
40 ÷ 20.000 Hz
Microphone input MIC.3/UNITS
Balanced XLR (phantom supply 17,5 V) / 1 RJ45 (B711-G base station unit)
Sensitivity / Impedance
MIC.: 0,9 mV / 900 Ω - UNITS: 290 mV / 700 k Ω
S/N Ratio
MIC.: >62 dB – UNITS: >65 dB
Frequency response
40 ÷ 20.000 Hz
Maximum number of microphone station units (B711-G)
Up to 6 microphone stations in cascade fashion over a maximum distance of up 200 m
Microphone / Line input (MIC / LINE 4)
Balanced XLR with Phantom/Mic/Line selection
Sensitivity / Impedance (MIC / LINE 4)
MIC: 0,9 mV / 900 Ω - LINE: 90 mV / 50 kΩ
S/N Ratio MIC / LINE 4
MIC: >62 dB – LINE: >70 dB
Frequency response MIC / LINE 4
40 ÷ 20.000 Hz
Auxiliary inputs
2 unbalanced, RCA (CD, TAPE)
Sensitivity / Impedance
450 mV (CD) – 230 mV (TAPE)
S/N Ratio
>70 dB
Frequency response
35 ÷ 20.000 Hz
Telephone / Emergency (TEL / EMERG) audio input
Balanced with terminals (HOT-COM-GND) with activation threshold adjustment
Sensitivity / Impedance
150 mV / 6 kΩ
S/N Ratio
> 72 dB
Frequency response
250 ÷ 17.000 Hz
Line signal outputs
Unbalanced, RCA
LINE OUT
900 mV / 100 Ω
Mains power supply
230/115 Vac - 50/60 Hz / 24 Vdc
Maximum consumption
130 W (150 VA)
270 W (320 VA)
24 Vdc current consumption (max power / with no signal)
3,4 A / 0,1 A
6,7 A / 0,2 A
19" rack mounting (modular units)
Optional AC3500 brackets (2U)
Dimensions (W x H x D)
430 x 88 x 234 mm
Weight
6,5 kg
9 kg
MODEL
AX3504
Rated power output
40 W
Constant voltage outputs / Low impedance outputs
100-70-50 V and 8 Ω
Tones control
Bass ± 10 dB (100 Hz) ; Treble ± 10 dB (10 kHz)
Microphone inputs MIC.1 and MIC.2
2 balanced (MIC1:Jack 6,5 mm, no phantom - MIC2: XLR with phantom power supply 16,5 V)
Sensitivity / Impedance
1 mV / 1300 Ω
S/N Ratio
MIC.1 >64 dB; MIC.2: >61 dB
Frequency response
35 ÷ 20.000 Hz
Auxiliary inputs
2 unbalanced RCA (CD, TAPE)
Sensitivity / Impedance
520 mV (CD) – 250 mV (TAPE)
S/N Ratio
>73 dB
Frequency response
30 ÷ 20.000 Hz
Telephone / Emergency (TEL / EMERG) audio input
Balanced with terminals (HOT-COM-GND)
Sensitivity / Impedance
150 mV / 6 kΩ
S/N Ratio
> 73 dB
Frequency response
170 ÷12000 Hz
Line signal outputs
Unbalanced, RCA
LINE OUT
800 mV / 100 Ω
Mains power supply
230/115 Vac - 50/60 Hz / 24 Vdc
Maximum consumption
100 W (117 VA)
24 Vdc current consumption (max power / with no signal)
2,8 A / 0,1 A
19" rack mounting (modular units)
Optional AC3504 brackets (2U)
Dimensions (W x H x D)
275 x 88 x 230 mm
Weight
4,2 kg
